An end plate connection consists solely of a vertical plate shop-welded to the end of the web transverse to the axis of the beam with fillet welds on each side of the web.
The field connection is made by bolting the end plate to the flange or web of the supporting member.
Axial tension tends to straighten the beam, thus counteracting the bending moments produced by the transverse load. On the other hand, since axial compression may greatly increase the bending moment and the slope and deflection of the beam, it is the more serious type of axial load.
